For weeds such as black-grass, mapping plant populations and poor yield areas with a handbook or GPS will allow better targeted patch-spraying. The latest drone technologies can also be used to map the presence and severity of weed populations, with the data produced subsequently being used to alter seeding rates and/or cultivation technique to counter the effects of weed competition.
Additional information regarding the use of weed mapping technologies and how they can be used on farm is available via the following links:
The drive for improved cereal yields led to many crops being drilled earlier than they might have been as recently as 10-20 years ago. Typical drill dates were previously into October, but as much as 50% of winter wheat has been drilled in September up to a few years ago. This scenario enabled black-grass populations to thrive and increase because there is no fallow period in which the first flush of weeds can be allowed to emerge and tackled with a glyphosate application.
As well as enabling the first flush of black-grass seedlings to be destroyed, delaying drilling can also improve the efficacy of pre-emergence herbicides which will be more effective when applied in damp soil conditions which are more favourable for good chemical activity. Black-grass plants which emerge in later drilled crops also tend to be less competitive and produce fewer seeds per plant.
Time of drilling is therefore key in the fight against black-grass: delaying drilling until as late as possible (mid-October onwards) is the main advice, but there could be a reduction in terms of final yields. The risk of the weather breaking and preventing late-season drilling from taking place also needs to be weighed up.
The prevalence of autumn-sown cropping is a key factor in the increase of black-grass within the UK. One simple way of tackling the problem is therefore to adopt a more balanced rotation through the inclusion of spring-sown crops such as spring barley which is more competitive than spring wheat: putting a spring crop in the rotation provides the opportunity to control newly emerged black-grass plants – via mechanical or chemical means – prior to them producing seeds and ahead of the ensuing crop being drilled.
Competitive/companion crops can also be used to suppress black-grass plants, with the AHDB citing 22-26% control. Similarly, cover-cropping or the use of grass ley breaks can also be effective at out-competing black-grass and can reduce the black-grass seed bank by 70-80% per year. It is however important to remember that a one-year grass ley will rarely be long enough to reduce high black-grass populations sufficiently. A break of 2-3 years is therefore advisable as this could reduce the number of viable black-grass seeds by as much as 90%. At the end of any break, a sufficient period of time between cultivation and sowing the next arable crop should be factored in to allow any subsequent flushes of black-grass to be destroyed.
The latest advice from Rothamsted Research is for growers to adopt a comprehensive range of strategies to tackle back-grass for a period of at least 5 years. This “5-for-5” strategy is explained in more detail here.
Where black-grass populations are low, or just starting to appear, spraying off patches of infestation with glyphosate in the first week of June, or hand rogueing to physically remove the plants before they shed their seed are effective methods of control. These strategies are, however, less feasible on land where extensive black-grass populations exist.
Choosing a variety that has a more prone growth characteristic may enable the crop to out-compete emerging black-grass plants. Trials looking at the effect of increasing seed rates to further compete with weeds are ongoing, with many growers already adjusting seeding rates on land known to have a high black-grass risk.
Keeping tractors, sprayers and implements free of weed seeds is a very simple way of minimising the spread of black-grass. A compressed air-line is an excellent tool for removing lodged seed from tight spaces, while harvesting the worst-affected areas last can reduce the risk of spreading black-grass (and fungal diseases) into cleaner fields. Where there is a risk of straw or manure acting as a source of contamination, it is prudent to err on the side of caution and to minimise their use.
Research shows that residual herbicides work well against black-grass when the seeds are located in the top 5cm of the soil. Conversely, seeds which are buried a little deeper (typically 5-10cm) will be less susceptible to chemical control – failure to control black-grass in shallow, non-inversion tillage systems can therefore result in a rapid increase in infestation.
Burying black-grass seeds down to a depth of 15-20cm by ploughing can reduce the seeds’ viability: black-grass seeds are relatively non-persistent, declining in viability by about 70-80% per year. There is however is a risk that some of the remaining 20% of viable seed could be ploughed back up again later in the rotation.
The advice, therefore, is to use min-till or shallow tillage cultivation in tandem with a robust chemical control programme for at least four years, with ploughing used on a rotational basis.
Before any weed control programme is formulated, it is important to remember that the improper use of crop protection chemicals (too many applications, too few applications, dose rates which are too high or too low) can affect the efficacy of active ingredients, and in the worst cases, further exacerbate the rate of resistance build up. Growers are therefore advised to seek professional advice before changing the accepted application protocols for any herbicide and to consider using a range of active ingredients instead of relying on just one mode of action.
The decline in recent years of achieving effective black-grass control with post-emergence herbicides has forced growers to use ever more complex and expensive combinations of active ingredients, with many of these chemicals now being used at pre-emergence timings.
The need for effective pre-emergence herbicides is expressed very clearly in AHDB Information Sheet 30 (click here to download)
When selecting products to control black-grass in winter wheat, there are a number of options to choose from. However, looking at the effective options more closely reveals the number of active ingredients available within those products is significantly limited.
When planning the use of a pre-emergence herbicide, it is fundamentally important that the application is made at a true pre-emergence timing; ideally within 48 hours of drilling, and certainly not delayed until some emergence of the crop or black-grass has begun.
In most situations, it would be unwise to apply a product with a single mode of action, as relying on one active ingredient could not only reduce the efficacy of the overall crop protection programme, but could also make the lone active more susceptible to resistance.
Of the active ingredients currently available, and which are still capable of contributing to a successful black-grass control programme, the most widely-used are:
Each of these is available as standalone products, as well as being available in combination with other actives. Of these, the cornerstone active ingredient for pre-emergence treatments is flufenacet, typically applied at 240 gai/ha.
Flufenacet should not be exposed by applying it alone, but, instead, should be mixed with other active ingredients which have a different mode of action. Choices available, in addition to those already mentioned, include:
The best results will be achieved when pre-emergence applications are made to moist, fine, firm seedbeds, in a minimum water volume of 200 litres per hectare and using a combination of forward-facing and rear-facing nozzles. Acceptable results are possible with lower water volumes, provided good coverage of the soil surface is achieved.
In the worst black-grass areas, the herbicide programme is typically started with a pre-emergence application of 240 gai/ha flufenacet, in combination with one or more of the options mentioned above. This can then be followed with a further 120-240 gai/ha of flufenacet at early post-emergence, again in mix with other active ingredients with activity on black-grass.
The post-emergence application should be made when any black-grass plants not controlled by the pre-em treatment are at the one-leaf to two-leaf stage, although this may not always be possible in all scenarios as an interval of six weeks is required between sequential applications of flufenacet.
In a perfect world, pre-emergence applications would be followed by enough rainfall to aid the efficacy of the active ingredients, but not so much that subsequent post-emergence treatments can’t be applied. Unfortunately, the UK’s unpredictable weather all too often dictates that pre-emergence treatments will be followed by excessively wet or dry conditions. In both cases, the weather will have a detrimental impact on the efficacy of the pre-emergence treatment.
In addition to selecting an herbicide active ingredient based on its reliability and efficacy, consideration should also be given to its ability to remain effective in variable seedbed conditions. The following factors should therefore be assessed, with the finalised spray programme customised and adapted using a combination of active ingredients to suit the prevailing field conditions:
PPDB: Pesticide Properties DataBase – University of Hertfordshire https://sitem.herts.ac.uk/aeru/ppdb/ - Accessed – May 2017
For heavily infested soils, a peri-emergence application (when leaves are breaking the soil surface, but the first leaf is not fully expanded) may also be worth considering. A later post-emergence treatment, before the end of December, and ideally before the black-grass plants grow beyond three true leaves, may also be needed.
In these circumstances it will be necessary to exceed 240gai/ha of FFT. However, no more than 240 gai/ha can be delivered by one product in a single application: different products will therefore need to be used if all applications are to be made before the end of December.
If DFF is being used, no more than 125 gai/ha should be applied in total. For PDM the limit for a single application is 1,320 gai/ha, while the maximum total dose is 2,000 gai/ha. Products containing CTU may not be applied more than once per year on the same area of land.
Use non-chemical methods in combination with herbicides to improve control;
Use a mix of active ingredients with different modes of action;
Apply a robust pre-emergence stack within 48 hours of drilling;
Ensure good application coverage by using forward and rear-facing nozzles to apply pre-emergence treatments to a fine, firm seedbed;
Keep the water volume up to ensure sufficient coverage;
Keep the sprayer’s forward operating speed reasonable: 12 km/h will ensure accurate coverage;
Return with a post-emergence treatment when black-grass plants are the one/two leaf stage;
Tailor treatments to each individual field according to soil type, rotation, previous cultivation technique and current black-grass populations.
A unique residual herbicide containing three active ingredients: pendimethalin, diflufenican and chlorotoluron. It is effective against black-grass when used in a programme and provides excellent standalone control of annual meadow-grass and broad-leaved weeds in winter and spring cereals.
Contains 250g/l chlorotoluron, 40g/l diflufenican and 300g/l pendimethalin.
A contact and residual broad spectrum herbicide containing the leading grassweed ingredient, flufenacet, plus diflufenican. When applied at 0.3l/ha, Herold delivers 120 gai/ha flufenacet and 60 gai/ha diflufenican, so is an excellent choice for the pre-emergence treatment.
Contains 400g/l flufenacet and 200g/l diflufenican.
A long-lasting and reliable residual herbicide containing pendimethalin. It provides a good foundation for control programmes targeted at tough grass and broad-leaved weeds in cereals.
Contains 400g/l pendimethalin.
A residual herbicide containing diflufenican. It is a key herbicide for the control of black-grass and can also be used to control a broad spectrum of broad-leaved weeds and annual meadow-grass. Hurricane® SC can be added to Herold® to improve black-grass control.
Contains 500g/l diflufenican.
A broad spectrum residual herbicide containing two active ingredients: diflufenican and pendimethalin. It is an excellent tank mix partner for the control of black-grass and wild oats and is also effective against broadleaved weeds in winter and spring cereals.
Contains 40g/l diflufenican and 400g/l pendimethalin.
Spinnaker is used for the control of annual grassweeds and annual broad-leaved weeds in winter barley, winter wheat and early and maincrop potatoes.
Contains 800 g/l prosulfocarb.
A residual herbicide for use in winter cereals for the control of black-grass, annual meadow-grass and some broad-leaved weeds.
Contains 500 g/litre (42% w/w) flufenacet
All weeds compete for sunlight, water and nutrients, with the main impact on commercial arable crops being a reduction in yield.
The impact of each individual weed species is measured on a scale known as the ‘competitive index’: a definition of how many weed plants per square metre will result in a 5% reduction in crop yield.
Because of its great ability to produce tillers, ryegrass needs only 5 plants/m2 to cause a 5% yield loss. However, even though black-grass is ranked as less competitive on the index, with 12 plants/m2 causing a 5% yield loss, it poses a greater real-world problem. This is because its populations can be extremely high: it’s not unusual to have more than 1,000 black-grass plants/m2, creating a dense carpet of weeds in the autumn.
It is commonplace to get a 25% yield loss where black-grass is present, with the cost of a typical herbicide programme to control it as high as £150/ha.
The natural lifecycle of black-grass is well-suited to the UK’s arable system, with its ability to mature and shed seeds before the arable crop can be harvested adding to the weed’s capacity to prevail and persist.
As each black-grass seed head is capable of producing up to 100 seeds, control levels of 97-98% of the population are required simply to keep pace with the weed threat and to prevent the seed reservoir within arable soils from increasing.
ADAMA is currently developing a new range of herbicides specifically designed to control black-grass in cereals.
The new ‘ALOMAX’ range will include three formulations, all of which will contain three active ingredients and three modes of action: diflufenican (DFF), flufenacet (FFT) and pendimethalin (PDM).
A replicated field trial was setup to investigate the performance of ALOMAX 433 versus the current market standards. Within the trial ALOMAX 433 was applied alone pre-emergence, in mixture with ADAMA’s prosulfocarb (Topsail) and alongside Avadex granules. In further treatments ALOMAX 433 was followed early post emergence by ADAMA’s Tower + 240g of flufenacet (Iconic).
A drone was used to develop a “heatmap” of black-grass head counts where red/orange pixels indicated black-grass and yellow/green recorded wheat. The drone image shows the high level of black-grass in the trial (723 heads/m2 in the untreated plot) and the strength of ALOMAX 433 when used alone pre-emergence compared with the current market standard. Additionally, where pre-emergence programmes were built then the number of black-grass heads is incrementally reduced especially when placed in combination with the Avadex granules. Furthermore, a programmed approach of ALOMAX 433 pre-emergence followed by Tower (2L) and flufenacet (240g) reduced the overall head count by over 56% in this trial without the additional benefits of non-chemical control methods.
